SFS-BX-01 Solar Roof Mounting System
-
Item No.:
SFS-BX -
Product Origin:
Xiamen, China -
Color:
Natural color -
Shipping Port:
xiamen port -
Lead Time:
15 days - Dimension: Customized
-
- Overview
- FAQ
- Recommended Products
- Residential & Commercial Rooftop PV Systems: Suitable for supporting small to medium-sized solar panels on flat or sloped rooftops. The adjustable angle design optimizes sunlight exposure based on local latitude, maximizing power generation efficiency without damaging the roof waterproof system.
- Outdoor Portable Solar Projects: Ideal for camping, off-grid cabins, and field workstations. It provides stable support for portable solar panels, powering outdoor equipment like lighting, communication devices, and small inverters. Foldable and lightweight, it’s easy to transport for on-site deployment.
- Ground-Mounted Distributed PV Installations: Perfect for rural, suburban, or industrial areas with open space. Compatible with fixed or temporary solar arrays, it resists wind and snow loads, ensuring long-term stability for ground photovoltaic systems.
- Solar Demonstration & Testing: Widely used in solar energy exhibitions, academic research, and product testing. The flexible adjustment allows for easy angle modification to test the impact of different sunlight orientations on panel performance.
Usage Precautions
- Do not exceed the maximum load capacity (please refer to product specifications) to avoid structural damage or solar panel fall-off, which may cause electrical hazards.
- Ensure all locking knobs and fasteners are tightly fastened before installing solar panels. Double-check stability after adjustment to prevent slipping or tilting due to wind pressure or external force.
- Avoid using the tripod on uneven, slippery or soft surfaces. For ground installation, use ground nails or anti-slip pads to reinforce stability, especially in areas prone to strong winds.
- Keep the tripod away from high temperature, open flames and corrosive substances. Ensure the tripod and solar panel connections are away from water accumulation to prevent electrical leakage.
- Do not disassemble the tripod without professional guidance. When adjusting the angle with installed solar panels, first disconnect the electrical circuit to avoid live-operation risks.
- Electrical Safety Note: All operations (installation, adjustment, maintenance) must be performed when there is no sunlight or after disconnecting the circuit to prevent electric shock from solar panel power generation.
Specification
Installation Site: open ground
Panel Dimension: Any Size
Panel Type: frameless panel or framed panel
Structural materials: aluminum, stainless steel
Survival wind speed: Up to 20m / s
Design snow pressure: Up to 0.5 KN / m2
Component direction: Horizontal
Tilt angle: Customized
Design Standards: BS 6399-2-1997
Life: 10 years on material
Features
1. The Angle size can be adjusted according to installation requirements
2. Adopt a screw combination with a handle to install, easy to disassemble
3. Simple structure light and easy to carry.
Application Scenarios
This solar panel-specific adjustable tripod is widely applicable to various photovoltaic scenarios, adapting to different on-site requirements with its flexible design and stable load-bearing capacity:
Certification of Solar Roof Rack for Home Solar System- Inquire with suppliers
Our customers visiting and PV EXPO
FQA
Q1: What is the adjustable height and angle range of the SFS-BX-01 solar panel tripod?
A1: The adjustable height range is [fill in specific range, e.g., 60cm-150cm], and the angle can be adjusted between 0°-60° (depending on specifications). This allows flexible adaptation to local latitude and seasonal sunlight changes to maximize solar energy absorption.
Q2: Can the tripod be folded for easy carrying?
A2: Yes, it features a foldable design. After folding, it is compact in size and lightweight, easy to carry with the matching storage bag for outdoor and on-the-go use.
Q3: How to deal with loose locking knobs?
A3: First, check if the knob is worn. If it is loose due to improper operation, tighten it gently. If the knob is worn or damaged, contact our after-sales service for replacement.
Q4: Is the tripod compatible with different sizes of solar panels?
A4: It is compatible with most small to medium-sized solar panels (e.g., 50W-300W) with standard mounting holes. The adjustable clamping mechanism fits different panel widths. For large or heavy-duty panels, please confirm the maximum load capacity before use.
Q5: What should I do if the tripod is damaged during use?
-
Storage: When not in use for a long time, disassemble and store the tripod in a dry, well-ventilated place. Avoid placing heavy objects on it to prevent deformation. Use the original storage bag for protection, especially for portable outdoor use.
-
Lubrication: Apply a small amount of anti-rust lubricating oil to the adjustable joints and locking mechanisms every 3-6 months to ensure smooth angle adjustment, which is crucial for optimizing solar panel orientation seasonally.
-
Rust Prevention & Inspection: After rain or snow, dry the tripod thoroughly as soon as possible. Regularly check for rust, paint peeling, or loose fasteners, and replace damaged parts promptly to avoid affecting the solar panel’s stability.
A5: Please stop using it immediately to avoid further damage. Contact our after-sales team with your purchase certificate and product photos for maintenance or replacement services.
For more inquiries about the SFS-BX-01 Adjustable Solar Panel Tripod, please reach out to us at [email protected].
