Aluminum Profile Portable Solar Mounting System Brackets Triangle Set Solar Panel Mount Easy Installation PV Racking System

-Mount Type: Sunforson portable solar panel mounting bracket
-Installation Site: Roof or Ground
-Panels: Solar panel for any size
-Structural materials: Aluminum, stainless steel
-Survival wind speed: Up to 20m/s

Overview
Recommended Products

SFS-BX-01 is suitable for RV, yacht, special vehicle, communication base station, it also can be used for roof, ground, wall and other outdoor small photovoltaic system installation.
The Angle size can be adjusted according to installation requirements
Adopt screw combination with handle to install, easy to disassemble
Simple structure light and easy to carry.

Mount Type	Sunforson portable solar panel mounting bracket
Installation Site	Roof or Ground
Panels	Solar panel for any size
Structural materials	Aluminum, stainless steel
Survival wind speed	Up to 20m/s
Design snow pressure	Up to 0.5KN/m2
Inclination	Customizable
Panel layout orientation	Horizontal
Design Standards	CE&AS / NZS 1170
Warranty	Design Life for 10 years, quality assurance for 5 years
